STA Multipac 7-092
STA Multipac drum mount 7-092 - dimension drawing
STA Multipac 7-092
STA Multipac drum mount 7-092 - dimension drawing

STA Multipac

Part Number: 7-092

Frequently Bought Together

Same Day Dispatch!

Need Help? 1300 799 990

Description

The STA Multipac Drum Mount 7-092 provides a flexible connection between the roller drum assembly and its support structure, helping isolate vibration during operation.

60 Shore A rubber is bonded to 8 mm zinc-plated Grade 250 steel plates, combining a resilient isolating element with defined steel mounting surfaces. Its rectangular mounting arrangement combines a 251 × 127 mm finished face with 226 × 101 mm fixing centres and a 100 mm overall thickness.

Key Features & Product Details

  • Specified rubber hardness: 60 Shore A rubber provides the flexible vibration-isolating element.
  • Grade 250 steel plates: 8 mm laser-cut plates form the mounting surfaces and fixing points.
  • Zinc-plated finish: a protective coating on the steel mounting plates.
  • Defined fixing arrangement: dimensions and fixing details are listed below.
Measurements
Measurement Specification
Finished face (L × W) 251 × 127 mm
Overall thickness 100 mm
Steel plate (L × W × T) 247 × 123 × 8 mm
Mounting holes per plate 4 × Ø13 mm
Mounting-hole centres (L × W) 226 × 101 mm
Compatible Models
STA Multipac
VV71-D
VV900
VV900D
VV1100
VV1400
VV1403
VV1500
VV2004
VV2010
OEM Part Numbers
Cross-reference numbers
20472
ND090010
ND090011
